Dimmer module KTE45BD

4-way thyristor dimming driver
● 4-channel thyristor dimming driver, with a maximum load of 500w per channel, using cutting-edge bidirectional thyristor dimming
● Can be used for incandescent lamps, low-voltage halogen lamps, and tube lamps/LED lamps with electronic adapters with thyristor input
● Adjustable dimming speed, opening time, with scene function, each channel can independently achieve switch control and dimming control

Dimming module KTE4110D

4-way 0/1-10V dimming driver
● 4-way 0/1-10V dimming driver with relay on/off function
● Support dimming transformers that match the Current Source/Current Sink module
● Manually control the opening/closing/dimming of each circuit
● Support relative dimming command (4 bits)
● Support absolute dimming command (1 byte)
● Scene function dimming speed can be set
● The gradient speed of the switch can be set and the brightness can be set to start
● 24V auxiliary power supply required

Dimmer module KTE41TD

4-way thyristor dimming driver
● 4-channel thyristor dimming driver, with a maximum load of 1000w per channel, using cutting-edge bidirectional thyristor dimming
● Can be used for incandescent lamps, low-voltage halogen lamps, and tube lamps/LED lamps with electronic adapters with thyristor input
● Adjustable dimming speed, opening time, with scene function, each channel can independently achieve switch control and dimming control
